Extrastep is a CAD agent for parts that have to fit.

Start a project How it works
Sensor enclosure · Extrastep
ProjectsSensor enclosure
The 3D view needs WebGL.

Drag to orbit · Shift-drag to pan · Click, then scroll to zoom

Revision 14 · Orthographic133 faces · 270 edges · 8 solids · 11,600 triangles

Brings in STEP. Hands back STEP, STL and 3MF.

STEPImport and export
STLExport, three mesh sizes
3MFExport, three mesh sizes
CadQuerySource download on plans that include it

Point at what you mean

Click a face, an edge or a whole part and it becomes a reference in your message. Hover a reference to see exactly what it points to.

Try it on the enclosure
Lid details
The LCD display face highlighted in brass inside the lid openingLCD · display face

Keep the opening centered on LCD · display face and move switch_2 2 mm toward +X, clear of lid · opening edge.

Design around the parts you already have

Attach STEP files for your board, display and switches. They stay exactly as imported and locked in place while Extrastep builds the enclosure around them.

Supported formats
Sensor enclosure · Extrastep

Parts

  • baseGenerated
  • lidGenerated
  • PCBImported
  • LCDImported
  • switchImported
  • switch_2Same file

Fit checks · Revision 14

  • Display opening31.0 × 13.0 mm
  • Around the display0.50 mm
  • Actuator holesØ 6.8 mm
  • Around each actuator0.40 mm
  • Lid and LCDno contact
  • Connector opening12.0 × 6.2 mm

Every turn is a revision

Your design is parametric source, rebuilt and checked after every change. Revert to any turn, fork a variant, and export the revision you want.

Start a project
Sensor enclosure · Extrastep

History

  1. 14Lid: display opening and actuator holesnow
  2. 13Base: connector opening6 min
  3. 12Base: standoffs and screw columnsRevert hereFork9 min
  4. 11Layout: PCB, LCD and two switches, locked24 min
Reverted · 2 turns

Export · Revision 14

  • PartsAll 6
  • FilesOne combined
  • PositionsAs assembled
Export STEP

Exact by default

  • Display opening31.0 × 13.0
  • Actuator holesØ 6.8
  • Lid and switchesno contact
  • Views reviewediso · top

Checked before you see it

Each change is measured against your request, then reviewed from fresh isometric and orthographic views before it is published.

Ø3.2 THRU ×4

Exact geometry, not a mesh

Results are solids built from parametric source, so a 3.2 mm hole is still a 3.2 mm hole in the STEP file you export.

ProjectionOrthographic
SectionZ 12.0 mm
Hiddenlid
Agentworking

Your view stays yours

Orbit, section and hide parts while the agent works. When the result arrives, the camera stays where you left it.

Start with the parts you have.
